A Half Pneumatic Cup Filler Machine is a type of semi-automatic filling machine that combines the benefits of both pneumatic and mechanical systems. This type of machine is equipped with a cup dispensing system, which dispenses a precisely measured volume of product into containers, but uses a mechanical mechanism to control the dispensing of the product. This can include a foot pedal, lever, or other manual control, which activates the dispensing of the product. The use of a pneumatic system provides a number of benefits, including improved accuracy and consistency of fill weights, as well as reduced contamination risk compared to purely mechanical systems. The manual control aspect of the machine provides increased flexibility and control for the operator, making it well-suited for smaller scale packaging operations. Half Pneumatic Cup Filler Machines can be used in a variety of industries, including food, pharmaceutical, and cosmetic, and can be custom designed to meet specific packaging needs.
| Machine Name | Half Pneumatic Cup Filler Machine |
|---|---|
| Filling System | Volumetric Cup Filler |
| Filling Capacity | 20gm to 50gm, 50gm to 100gm, 100gm to 250gm, 200 to 500gm (Exchange Cup Assembly) |
| Filling Accuracy | +/- 1 to 2% (Depend upon nature of Product) |
| Type of Sealing | Center Seal / 3 Side Seal / 4 Side Seal |
| Sealing System | By Air Cylinder |
| Bag Pulling System | Clutch Break Drive / Ac Drive |
| Film Roll Size | 50 to 350mm-Width / 50 to 200mm-Length |
| Film Material | Laminated Film in Roll Supported Film E.g.Aluminum Foil, PE, PP |
| Speed | 20 TO 45 Bag/min. (Varies with the nature of Product & Filling Range) |
| Machine Controlled | PLC / Logic Controller |
| Poweer Supply | 220V AC Single Phase |
| Machine Size | 900 x 900 x 3050mm (LXWXH) |
| Product Packet | All types of Pulses, Grains & Dal Etc.Detergent Powder, Salt, Sugar, Tea, Rawa,Suji, Etc. |
